The high-pressure pumps of the HP series are designed for pumping liquids in petrochemical plants, boiler feed water, condensate, reverse osmosis, oils, and fuels and are suitable for applications such as:
- boiler feed water applications
- applications in the oil and gas industry
- booster application in all industrial branches
- applications in refineries
- water injection onshore and offshore
- feed-water pump with intermediate take-off and optimized pressure design within the pump
- version with NPSH impeller
- axial thrust compensation by means of piston or double piston
- bearings: antifriction bearings or slide bearings
- Hydraulically balanced concept regarding the range of application, efficiency and rotor dynamics
- low vibration values
- long service life
Standard Version
Radial bearings: antifriction bearings
Axial bearings: antifriction bearings
Ring oil lubricationVariant
Radial bearings: slide bearings
Axial bearings: antifriction bearings
Ring oil lubricationVariant
Radial bearings: slide bearings
Axial bearings: slide bearings
Pressure oil lubrication
BB1 - ZMK
Axial split Pumps with bearings on both sides, Type BB1
Q= 10000 m³/h, H= 140 m, P= 25/40 bar, T= 150 °C
read more
BB2 - ZPR / ZPRA
Single-stage and 2-stage Pumps with bearings on both sides, Type BB2
Q= 1600 m³/h, H= 440 m, P= 55 / 64 bar, T= + 450 °C
read more
BB2 - KGR
Double-stage process pump with bearings on both sides, Type BB2
Q= 1600 m³/h, H= 600 m, P= 80 bar, T= + 450 °C
read more
BB2 - KGRD
Process pump with bearings on both sides, Type BB2
Q= 1600 m³/h, H= 600 m, P= 80 bar, T= + 450 °C
read more
BB3 - AMG
Multistage axially split high-pressure pump, Type BB3
Q= 3200 m³/h, H= 2200 m, P= 265 bar, T= +200 °C
read more
BB4 - GP
Multistage ring-section high-pressure pump, Type BB4
Q= 600 m³/h, H= 2500 m, P= 250 bar, T= +250 °C
read more
BB4 - GMHD
Ring-section high-pressure pump, Type BB4
Q= 1100 m³/h, H= 320 m, P= 63 bar, T= + 180 °C
read more
BB5 - TL
Barrel high-pressure pump, as in-line version, Type BB5
Q= 1800 m³/h, H= 2800 m, P= 350 bar, T= +400 °C
read more
BB5 - TG
High-pressure barrel pump, back-to-back version, Type BB5
Q= 1800 m³/h, H= 4200 m, P= 450 bar, T= +420 °C
read more
